Stahlkugellager (Stück) | 2 |
Lifetime lubricated | wartungsfrei |
Motor technology |
3-phasiger Asynchronantrieb (bürsten- und sensorlos) |
Frequency | 667 Hz |
Motor poles (pairs) | 2 |
Rated Rotation Speed | 20.000 rpm |
Rated Power (Pmax/5s) | 2 kW |
Rated Power (S6-60%) | 1,6 kW |
Rated Power (S1-100%) | 1,4 kW |
Voltage (Pmax/5s) | 179 V |
Voltage (S6-60%) | 178 V |
Voltage (S1-100%) | 180 V |
Current (Pmax/5s) | 8,6 A |
Current (S6-60%) | 6,5 A |
Current (S1-100%) | 6 A |
Speed Sensor |
Feldplatte (TTL) Anzahl Signale = 6 |
Motor protection | PTC 160° C |
Housing | Aluminium |
Housing diameter | 102,5 mm x 88 mm |
Cooling | Druckluftgekühlt |
Heat dissipation | über das Gehäuse |
Housing temperature | <+ 45° C |
Ambient temperature | + 10° C … + 45° C |
Sealing Air | yes |
Protection category | IP54 |
Tool Change | Manueller Werkzeugwechsel |
Tool Holder |
Scheibenwerkzeug Ø16 mm maximal t =3 mm |
Direction of motion | Linkslauf |
Coupler plug |
8-pol (SpeedTEC) Kabellänge1,15 m |
Weight | 2,1 kg |
Axial run-out | <1 µ |
